SWIR, MWIR, LWIR Cameras and Cores Provider

Analinear is an imaging solution company, providing Imaging Sensor IP's, Peripheral Analog IP's, Imaging SoC design and Specialized camera System products. Focused on its core competency.

Screen Shot 2020-09-02 at 10.36.39 AM.pn

We have a comprehensive portfolio of mixed signal IP's. Our proven nanometer SoC customers have benefited by putting their confidence in Analinear'scapabilities to meet tight time to market schedules with reduced design risk.

PYTHON​ Series

LWIR Thermal Camera

  • Resolutions: 640X480, 17um

  • Spatial Range: 8 to 14um (Asi Micro-bolometer)

  • Low-power (1.5W in TEC less mode)

  • On-board NUC, BPR, AGC

  • Camera-Link / Analog (CVBS Out)

  • Supports external trigger (<2W) in lowest Power Mode

  • NETD < 50Mk

  • Upto 50 FPS (for 640x480)

  • Shutterless Mode (Optional)

  • Time to Image < 4 seconds

  • Military Standard (MIL-STD-810G & MIL-STD461)

Download Brief

JAGUAR Series

Highest Quality SWIR Imaging

  • 640x512, 15um Pixel

  • Spatial Range: 0.9 to 1.7um (InGaAs detector)

  • 300 FPS Frame rate. Up to 5000Hz with windowing

  • CamLink, USB2.0, NTSC or PAL

  • Low Power (1.5W ) in lowest Power Mode

  • 14 Bit High dynamic Range and ultra-low noise design

  • Dimensions: 45mm x 45mm x 35mm

  • Weight: 120g

  • Military Standard (MIL-STD-810G & MIL-STD461)

Download Brief

Custom Camera Design

Analinear undertake custom design of Camera cores and Complete camera products for embedded or standalone applications in any of the IR wavebands as SWIR, MWIR, LWIR with CMOS sensors and in the visible band with CMOS and CCD sensors.

Analinear can work with the customer from a Functional specification level to the production manufacturing of the systems as OEM supplier.

Analinear developed Camera Cores which have been specifically designed for OEM camera manufacturers and system integrators. The complete engines are easy to plug and play. These IR Cores/engines can be customized for different OEM applications.

  • KEY FEATURES

    • 9-24V single power

    • Low-power (<1.5W TEC less mode)

    • Customizable for any imager format: QVGA to SXGA

    • Supports on-board NUC, BPR, AGC

    • Digital Output: Camera-Link, USB2.0

    • Analog (CVBS Out)

    • Supports external trigger

    • Programmable up to max 300 fps in window Mode

  • APPLICATIONS

    • Camera cores for IR Imagers

    • Camera engines for High performance APS sensors
